MSP 程控电源图片
The MSP-KONSTANTER (Multi-Output System Power Supply) offers extensive flexibility, ease of operation and economy for universal use in R&D, production and testing.
The MSP-KONSTANTER is a modular, manually operated and computer controlled DC power supply.
The basic unit with integrated auxiliary power supply and cooling fan is equipped with IEEE 488 and RS 232 interfaces, and accepts up to four single or 2-channel plug-in power supply modules and one control module.
The control module allows for operation of all 8 channels.
The plug-in modules function in accordance with the linear controller principle, and the outputs have a 2 quadrant operating range.
Source and sink functions are possible for constant voltage as well as constant current operation. Parallel or series connection, as well as bridging for the generation of bipolar voltages are possible.
The control module allows for operation of all 8 channels.
The plug-in modules function in accordance with the linear controller principle, and the outputs have a 2 quadrant operating range.
Source and sink functions are possible for constant voltage as well as constant current operation. Parallel or series connection, as well as bridging for the generation of bipolar voltages are possible.
- Up to 8 independent, electrically isolated outputs
- All outputs can be used as electronic loads as well
- Minimal residual ripple and short response times
- Output ON/OFF function
- Outputs can be activated and deactivated individually or in groups
- Measuring function for voltage, current and power with storage of extreme values
- Online help available in various languages by simply pressing a key
- IEEE 488 and RS 232 interfaces
- Easy, flexible device configuration
|
名 称
|
功率
（W）
|
电压
(V) |
电流
(A) |
型 号
|
订货号
|
|
MSP 64D
|
|
|
|
Basic device, 64 D 42 P
|
K370A
|
|
MSP Panel
|
|
|
|
Control module
|
K371A
|
|
MSP 48-2x8
|
2x24
|
2x0-8
|
2x0-±3
|
ES 31 K 2x8 R 3 P plug-in module
|
K372A
|
|
MSP 48-2x16
|
2x24
|
2x0-16
|
2x0-±1.5
|
ES 31 K 2x16 R 1.5 P plug-in module
|
K372B
|
|
MSP 48-2x40
|
2x24
|
2x0-40
|
2x0-±0.6
|
ES 31 K 2x40 R 0.6 P plug-in module
|
K372C
|
|
MSP 49-7
|
49
|
0-7
|
0-±7
|
ES 31 K 7 R 7 P plug-in module
|
K372D
|
|
MSP 120-30
|
120
|
0-30
|
0-±4
|
ES 32 K 30 R 4 P plug-in module
|
K373A
|
|
MSP 120-80
|
120
|
0-80
|
0-±1.5
|
ES 32 K 80 R 1.5 P plug-in module
|
K373B
|
